Hammer Crusher

Our PC series hammer crusher is mainly used to crush brittle mineral materials whose compressive strength is less than 100MPa, such as coal, salt, chalk, gypsum, alums, bricks, tiles, limestone, etc.

Video Show

Description of Hammer Crusher:
Our PC series hammer crusher is mainly used to crush brittle mineral materials whose compressive strength is less than 100MPa, such as coal, salt, chalk, gypsum, alums, bricks, tiles, limestone, etc.
It is mainly comprised of crusher frame, rotor, grate bars, and hammer. Rotors are directly driven by the motor via elastic coupling, and materials will be crushed under the impacting action of hammer head to the crushing plate.
Technical Parameters of PC Series Hammer Crusher:

Model
rotor working diameter / length(mm)
Rotating Speed of rotors (r/min)
Feeding Size (mm)
Max.feeding size (mm)
Discharging size (mm)
Handling Capacity (t/h)
Motor Power (kw)
Weight (t)
Overall Dimensions (mm)
PC-41
Ф400/175
1000
145×270
50
3
0.5
5.5
0.5
812×1056×1315
PC-44
Ф400/400
1500
145×450
100
10
5~8
7.5
0.9
744×942×878
PC-64
Ф600/400
1000
295×450
100
15
10~12
18.5
1.03
1054×972×1117
PC-66
Ф600/600
1000
295×570
100
10
12~18
45
2.14
1315×840×1501
PC-86
Ф800/600
1000
350×570
200
10
20-25
55
2.45
1515×2586×1040
PC-88
Ф800/800
1000
350×850
200
15
35-45
55
3.05
1515×2831×1040
PC-108
Ф1000/800
1000
580×850
200
13
25-40
110
6.5
3206×2210×1515
PC-1010
Ф1000/1000
1000
580×1060
200
15
40-60
132
7.59
3514×2230×1516
PC-1010
Ф1000/1000
1000
580×1060
200
10
30-50
160
7.59
3514×2230×1518
PC-1010
Ф1000/1000
1000
580×1060
200
8
25-35
185
7.59
3514×2230×1518
PC-1212
Ф1250/1250
750
650×1330
200
20
90-110
185
19.1
4475×3162×2250
PC-1414
Ф1400/1400
750
1050×1540
250
20
120-170
280
17.2
2790×2800×2310
PC-1618
Ф1600/1800
590
1200×1740
350
20
220-280
500
32.4

Note: Parameters in the form are only for reference, and specific ones should refer to the particular contract.
Established in 1994, Jiangsu Pengfei Group Co., Ltd is a professional manufacturer of hammer crusher in China. Besides hammer crusher, we also provide customers worldwide with Single- stage hammer crusher, air tank pulse bag dust filter, cement production line, cement grinding plant, industrial kiln and furnace, grinding equipment, crushing equipment, environmental protection equipment, cooling equipment, drying equipment, compound fertilizer equipment, packing machine, chemical equipment and electrical control system. With the certification of ISO9000 and CE, our products have been well received by customers from as many as .
